3D Capability | - 2D to 3D Conversion: Yes13
- Dynamic Lamp Control: Yes
- 3D Glasses Brightness Adjustment: Yes
- Effect Adjustment(s): Yes
- Format(s): Frame Packing/ Side by Side/ Over-Under/Simulated 3D/ESPN 3D format/ 720p / 60 SBS
- Transmitter: Optional external transmitter (TMR-PJ2)
- Glasses: Optional rechargeable glasses (TDG-PJ1)
|
---|
Display | - Throw Ratio (standard lens): 1.27:1 to 2.73:1
- Throw Ratio (short throw lens): 0.8:1 to 1.0:1
- Display Resolution: 4096 x 2160 (Full 4K)
- Screen Size: 40" to 300" measured diagonally (projected)
- Display Technology: SXRD™ Technology
- Lens: All range Crisp focus (ARC-F) Lens
|
---|
General | - Integration Partner: Yes (Control4® Certified, AMX Device Discovery, Crestron Integrated Partner, Savant Partner in Excellence, RTI & URC)
- Acceptable Computer Signals: fH: 19 to 72 kHz, fV: 48 to 92 Hz, fV: 60 Hz
- Information Menu: Horizontal and Vertical frequency display
- Input A: D-sub 15 Pin, Analog RGB/Component
- Lens Control: Motorized focus, shift and
|
---|
Inputs and Outputs | - Component Video (Y/Pb/Pr) Input(s): 1
- Composite Video Input(s): 1
|
---|
Convenience | - IR Receiver: Front & Rear, Front, Rear
- Image Flip: HV, H, V, Off
- Multiple Language Display: 15 languages (including English, French, Spanish, German, and Chinese)
- Remote Control: Yes (RMPJ22)
|
---|
Installation Features | - Shift Range: V: +/- 0.80V; H: +/- 0.31H
- Ultra Low Fan Noise: 22dB
- Zoom: Yes- Motorized 2.1X
|
---|
Operating Conditions | - Operating Humidity: 35 to 85% (no condensation)
- Operating Temperature: 41°F to 95°F
|
---|
Video | - Contrast Ratio: 1,000,000:1 Dynamic Contrast
- Picture Position: Yes, lens-less anamorphic. 5 user selectable settings.
- Picture Modes: 9 Modes for 2D and 3D (Cinema 1/2/Digital, Reference, TV, Photo, Game, Bright Cinema, Bright TV)
- Picture Settings: Independent 2D and 3D Picture Settings
- Video Calibration Settings: 11 gamma adjustments, Black and White Level Adjustments, Real Color Processing v2 including Luminance Adjustment
- 12-bit Video Processing: Yes
- Signal: 80/60i, 576/50i, 480/60p, 576/50p,720/60p, 720/50p, 1080/60i, 1080/50i, (HDMI only): 1080/60p, 1080/50p, 1080/24p, 3840 x 2160/24p, 3840 x 2160/25p, 3840 x 2160/30p, 4096 x 2160/24p, 4096 x 2160/60p
- Iris: Yes, Advanced Auto Iris 3
- Lens Shift Function: Yes (Motorized)
- Motionflow™ Technology: Yes with Dark Frame Insertion
- Video Processing: Yes with Block and Mosquito Noise Reduction
- x.v.Color™ Technology: Yes
|
---|
Approximate Dimensions | |
---|
Approximate Weight | |
---|
Warranty | - Three Year Limited Parts and Labor
|
---|
|
